Standard diameters:

89/63, 108/63, 108/89, 133/89, 133/108, 159/133

Design

• construction pipe longitudinally welded EN 10 219, 3 mm thick
• drawn steel round dia. 20 mm, h9, cl. 11109
• rubber wheels / wheels 68 +/- Shore A 89, 108, 133 or 159 mm in diameter
• steel lids from deeply drawn plate 2 mm thick, welded to the roller body (their design may vary depending on the roller diameter)
• bearing 6204 2RS C3
• four-part labyrinth seal with cap in ZN design (galvanized sheet)
• securing ring for shaft D20
• surface finish RAL 9005 black

It can be supplied with rings to prevent the rollers from sliding along the cylinder body

Example how to order

Rubberized 108/63/250/6204/20/14, L1=258, L2=278 mm – 10

surface finish RAL 5015 blue, four-part labyrinth seal ZN cap

Wheels and discs can be freely combined.

Dimensions not listed in the table will be produced after customer’s specification.
