Standard diameters:

51, 63, 76, 80, 89, 108, 133, 159

Design

• construction pipe longitudinally welded EN 10 219, thickness 3 mm (up to Ø108 mm)
• drawn steel round dia. 20 mm, h9, cl. 11109
• steel lids from deeply drawn plate 2 mm thick welded to the roller body (their design may vary depending on the roller diameter)
• bearing 6204 2 RS C3
• four-part labyrinth seal with a cap in ZN design (galvanized sheet)
• securing ring for a shaft D20
• end cap made of PE black (RAL 9003)
• surface finish RAL 5015 blue

Example how to order

Guarding 51/160/6204/20 with a recess – 10 pcs

surface finish RAL 5015 blue

Dimensions not listed in the table will be produced after a customer‘s specification.

The shaft mounting can be adjusted.
